Lenovo GCM16 KVM Switchbox

  • Part: 1011605
$6,036.00

Availability

Out of Stock

  • General Information
    • Manufacturer
    • Lenovo Group Limited
    • Manufacturer Website Address
    • http://www3.lenovo.com/au/en
    • Brand Name
    • Lenovo
    • Product Type
    • KVM Switchbox

The IBM Global 2X2X16 Console Manager (GCM16) and IBM Global 4X2X32 Console Manager (GCM32) are the next generation digital keyboard-video-mouse (KVM) console managers that provide KVM-over-IP and serial console management technology in a single appliance. Either console lets you access and manage all servers remotely, even to the system BIOS, using your existing IP infrastructure. The GCM16 has 16 target ports and supports up to 2 local users and 2 remote users, and the GCM32 has 32 target ports and supports up to 2 local users and 4 remote users. Figure 1 shows these two models.

  • Warranty
    • Limited Warranty
    • 3 Year

  • Technical Information
    • Number of Computers Supported
    • 16
    • Number of Local Users Supported
    • 2
    • Number of Remote Users Supported
    • 2
    • Daisy Chain Supported
    • Yes
  • Video
    • Graphic Mode
    • WSXGA+
    • Maximum Video Resolution
    • 1680 x 1050
  • Interfaces/Ports
    • Network (RJ-45)
    • Yes
    • USB
    • Yes
    • VGA
    • Yes
    • Number of Network (RJ-45) Ports
    • 3
    • Number of USB Ports
    • 4
    • Number of VGA Ports
    • 1
  • Power Description
    • Input Voltage
    • 220 V AC
    • 110 V AC
  • Physical Characteristics
    • Form Factor
    • Rack-mountable
    • Rack Height
    • 1U
    • Height
    • 43.7 mm
    • Width
    • 431.8 mm
    • Depth
    • 233.7 mm
    • Weight (Approximate)
    • 3.18 kg
  • Miscellaneous
    • Package Contents
      • GCM16 KVM Switch
      • Mounting Hardware
      • 1 x 1U Filler Panel
      • 2 x C13/C14 Rack Power Cables
      • RJ45-DB9F DCE Adapter
      • RJ45-DB9M DTE Adapter
      • 16 Terminators
      • Installation Publications and Warranty
