The Matrox M9120 PCIe x16 ATX graphics card renders pristine image quality with dual monitor support at resolutions up to 1920x1200 (digital), or 2048x1536 (analog) for an exceptional multi-display user experience. Armed with 512MB of graphics memory and advanced desktop management, the M9120 drives business, government, and industrial applications with extraordinary performance on two high-resolution monitors in both independent and stretched desktop modes. It offers multiple operating system support and can be paired with a second Matrox M-Series graphics card if additional outputs are required.
Features
- High-resolution dual monitor support: Support resolutions up to 1920x1200 (Digital) and 2048x1536 (Analog) per output
- Native PCI express x16 performance: Maximum bandwidth to ensure best performance
- 512 MB of memory: For enhanced performance in demanding multi-monitor applications
- ATX form factor
- Passive cooling and low power consumption: Fanless design eliminates noise and increases product reliability
- Stretched and independent desktop modes : Expand your desktop across multiple monitors or set each monitor independent of each other
- Edge Overlap: Easily and intuitively adjust the number of overlapping pixels to create a seamless, unified image on up to eight edge blending projectors.
- M-Series multi-card support1 : Add an additional M-Series card into the same system to drive up to 10 displays from two cards
- Joined graphics card mode2 : Insert two M-Series cards into the same system to drive even more monitors across a stretched desktop
- Matrox Clone : View a copy of one display on the other displays
- Wide enterprise flexibility: Unified driver package compatible with other Matrox products
- Matrox PowerDesk software: Easily configure and manage program windows on multiple monitors
- Multiple operating system support : Display drivers for Microsoft® Windows® 10 (32-bit, 64-bit; non-WHQL), Windows Server® 2012 (32-bit, 64-bit), Windows 7 (32-bit, 64-bit), Windows Embedded Standard 7 (32-bit), Windows Vista® (32-bit, 64-bit), Windows Server 2008 R1 (32-bit, 64-bit), Windows Server 2008 R2, Windows XP (32-bit, 64-bit), Windows Server 2003 and Linux®3
1. Operating system, hardware and driver compatibility need to be verified for large monitor configuration arrays. Contact Matrox for details.
2. Available only under Microsoft XP and Windows 7 XDDM mode when M9188 is the additional card.
3. M-Series cards support a wide range of Linux operating systems. Refer to the README file in the driver download section for compatible Linux distributions or contact Matrox directly.
- General Information
- Manufacturer
- Matrox
- Manufacturer Website Address
- https://www.matrox.com/en/video
- Brand Name
- Matrox
- Product Series
- M
- Package Type
- Retail
- Product Type
- Graphic Card
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Analog Signal
- Yes
- Digital Signal
- Yes
- API Supported
- DirectX 9.0
- OpenGL 2.0
- Number of Monitors Supported
- 2
- Processor & Chipset
- Chipset Manufacturer
- Matrox
- Chipset Series
- M
- Chipset Model
- M9120
- Memory
- Standard Memory
- 512 MB
- Memory Technology
- DDR2 SDRAM
- Interfaces/Ports
- Host Interface
- PCI Express x16
- DVI
- Yes
- Total Number of DVI Outputs
- 2
- Physical Characteristics
- Height
- 111.2 mm
- Length
- 167.6 mm
- Miscellaneous
- System Requirements
Supported Operating Systems (software):
- Windows 7 (32-bit, 64-bit)
- Windows 8.x (32/64 bit)
- Microsoft® Windows® 10 (32-bit, 64-bit; non-WHQL)
- Windows Embedded Standard 7 (32*/64 bit)
- Windows Server® 2003 (32/64bit)
- Windows Server 2008 R1 (32-bit, 64-bit)
- Windows Server 2008 R2
- Windows Server 2016 Windows Server® 2012 (32-bit, 64-bit)
- Windows Server® 2016 R2
- Windows Server 2019 Windows Vista® (32-bit, 64-bit)
- Windows XP (32-bit, 64-bit) Linux®*
'M-Series cards support a wide range of Linux operating systems. Refer to the README file in the driver download section for compatible Linux distributions or contact Matrox directly.
- Platform Supported
- PC
- Environmentally Friendly
- Yes
